AEH20F24

Part No :: AEH20F24

Manufacturer: Emerson Embedded Power (Artesyn Embedded Technologies)

VIGOR # :: 5040810

Description: DC DC CONVERTER 3.3V 66W

Catalog: DC DC Converters

DataSheet: AEH20F24 PDF

Country of origin: -

Date code: -

AEH20F24 Specifications

Type	Description
Series:	AEH20 (150W)
Package:	Bulk
Part Status:	Obsolete
Type:	Non-Isolated PoL Module
Number of Outputs:	1
Voltage - Input (Min):	18V
Voltage - Input (Max):	36V
Voltage - Output 1:	3.3V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	20A
Power (Watts):	66 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	Remote On/Off
Operating Temperature:	-40°C ~ 100°C
Efficiency:	87%
Mounting Type:	Through Hole
Package / Case:	9-DIP Module
Size / Dimension:	2.40" L x 2.30" W x 0.50" H (61.0mm x 58.4mm x 12.7mm)
Supplier Device Package:	-
Control Features:	Enable, Active High
Approval Agency:	-
Standard Number:	-

Alternative Products

Part Number	Manufacturer & Description	Compare
AEH10F24N Match 57%	Emerson Embedded Power (Artesyn Embedded Technologies) DC DC CONVERTER 3.3V 50W	AEH20F24 vs AEH10F24N
AEH20G24N Match 61%	Emerson Embedded Power (Artesyn Embedded Technologies) DC DC CONVERTER 2.5V 50W	AEH20F24 vs AEH20G24N
AEH20G24 Match 61%	Emerson Embedded Power (Artesyn Embedded Technologies) DC DC CONVERTER 2.5V 50W	AEH20F24 vs AEH20G24
AEH20F24N Match 100%	Emerson Embedded Power (Artesyn Embedded Technologies) DC DC CONVERTER 3.3V 66W	AEH20F24 vs AEH20F24N
AEH10F24 Match 57%	Emerson Embedded Power (Artesyn Embedded Technologies) DC DC CONVERTER 3.3V 50W	AEH20F24 vs AEH10F24
