PT5109J

Part No :: PT5109J

Manufacturer: Texas Instruments

VIGOR # :: 5042843

Description: DC DC CONVERTER 5.6V 5W

Catalog: DC DC Converters

DataSheet: PT5109J PDF

Country of origin: -

Date code: -

PT5109J Specifications

Type	Description
Series:	PT5100
Package:	Tray
Part Status:	Obsolete
Type:	Linear Regulator Replacement
Number of Outputs:	1
Voltage - Input (Min):	9.6V
Voltage - Input (Max):	38V
Voltage - Output 1:	5.6V
Voltage - Output 2:	-
Voltage - Output 3:	-
Voltage - Output 4:	-
Current - Output (Max):	1A
Power (Watts):	5 W
Voltage - Isolation:	-
Applications:	ITE (Commercial)
Features:	OCP, OTP
Operating Temperature:	-40°C ~ 85°C
Efficiency:	90%
Mounting Type:	Surface Mount
Package / Case:	3-SMD Module
Size / Dimension:	1.39" L x 1.00" W x 0.38" H (35.3mm x 25.4mm x 9.7mm)
Supplier Device Package:	-
Control Features:	-
Approval Agency:	-
Standard Number:	-
