JTV1S-PA-12V

Part No :: JTV1S-PA-12V

Manufacturer: Panasonic

Description: RELAY GEN PURPOSE SPST 20A 12V

Catalog: Power Relays, Over 2 Amps

DataSheet: JTV1S-PA-12V PDF

Availability: 4 pieces

Current price of JTV1S-PA-12V is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

JTV1S-PA-12V Specifications

Type	Description
Series:	JT-V
Package:	Bulk
Part Status:	Not For New Designs
Mounting Type:	Through Hole
Coil Voltage:	12VDC
Contact Form:	SPST-NO (1 Form A)
Contact Rating (Current):	20 A
Switching Voltage:	277VAC - Max
Coil Current:	83.3 mA
Coil Type:	Non Latching
Features:	-
Termination Style:	PC Pin
Seal Rating:	Sealed - Fully
Coil Insulation:	-
Must Operate Voltage:	9 VDC
Must Release Voltage:	1.2 VDC
Operate Time:	15 ms
Release Time:	10 ms
Operating Temperature:	-55°C ~ 85°C
Contact Material:	Silver Tin Oxide (AgSnO)
Relay Type:	General Purpose
