JTN1G-PA-F-DC48V

Part No :: JTN1G-PA-F-DC48V

Manufacturer: Panasonic

Description: RELAY GEN PURPOSE SPDT 20A 48V

Catalog: Power Relays, Over 2 Amps

DataSheet: JTN1G-PA-F-DC48V PDF

Availability: 0 pieces

Current price of JTN1G-PA-F-DC48V is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

JTN1G-PA-F-DC48V Specifications

Type	Description
Series:	JT-N
Package:	Bulk
Part Status:	Active
Mounting Type:	Through Hole
Coil Voltage:	48VDC
Contact Form:	SPDT (1 Form C)
Contact Rating (Current):	20 A
Switching Voltage:	277VAC - Max
Coil Current:	16.7 mA
Coil Type:	Non Latching
Features:	-
Termination Style:	PC Pin
Seal Rating:	-
Coil Insulation:	Class F
Must Operate Voltage:	36 VDC
Must Release Voltage:	4.8 VDC
Operate Time:	20 ms
Release Time:	10 ms
Operating Temperature:	-55°C ~ 85°C
Contact Material:	Silver Tin Oxide (AgSnO)
Relay Type:	General Purpose
