JTN1AG-PA-F-DC9V

Part No :: JTN1AG-PA-F-DC9V

Manufacturer: Panasonic

Description: RELAY GEN PURPOSE SPST 30A 9V

Catalog: Power Relays, Over 2 Amps

DataSheet: JTN1AG-PA-F-DC9V PDF

Availability: 0 pieces

Unit Price: ~~$3.07800~~

Current price of JTN1AG-PA-F-DC9V is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

JTN1AG-PA-F-DC9V Specifications

Type	Description
Series:	JT-N
Package:	Bulk
Part Status:	Not For New Designs
Mounting Type:	Through Hole
Coil Voltage:	9VDC
Contact Form:	SPST-NO (1 Form A)
Contact Rating (Current):	30 A
Switching Voltage:	277VAC - Max
Coil Current:	88.9 mA
Coil Type:	Non Latching
Features:	-
Termination Style:	PC Pin
Seal Rating:	-
Coil Insulation:	Class F
Must Operate Voltage:	6.75 VDC
Must Release Voltage:	0.9 VDC
Operate Time:	20 ms
Release Time:	10 ms
Operating Temperature:	-55°C ~ 85°C
Contact Material:	Silver Tin Oxide (AgSnO)
Relay Type:	General Purpose

Please confirm the specifications of the products when ordering.
