SP2-PL2-DC5V

Product image
Product thumb
Part No :

SP2-PL2-DC5V

Manufacturer
Panasonic
VIGOR # :

2691975

Description
RELAY GEN PURPOSE DPDT 15A 5V
Catalog
Power Relays, Over 2 Amps
DataSheet
SP2-PL2-DC5V PDF
Country of origin
Confirming
Date code
TBC
ads
SP2-PL2-DC5V Specifications
Type Description
Series:SP
Package:Tube
Part Status:Active
Mounting Type:Through Hole
Coil Voltage:5VDC
Contact Form:DPDT (2 Form C)
Contact Rating (Current):15 A
Switching Voltage:250VAC, 30VDC - Max
Coil Current:60.2 mA
Coil Type:Latching, Dual Coil
Features:-
Termination Style:PC Pin
Seal Rating:-
Coil Insulation:-
Must Operate Voltage:3.5 VDC
Must Release Voltage:-
Operate Time:30 ms
Release Time:30 ms
Operating Temperature:-50°C ~ 60°C
Contact Material:Silver Tin Oxide (AgSnO)
Relay Type:General Purpose
  • Please confirm the specifications of the products when ordering.
  • MOQ means the minimum order quantity required to purchase each parts.
  • If you have special order instructions,please note it on the ordering pages.
  • The Pre-Shipment Inspection (PSI) will be applied.
  • You can email us to change the order details before shipment.
  • Orders cannot be canceled after shipping the packages.
  • TT in advance (bank transfer), Credit Card, PayPal can be chosen.
  • Cash transfer only. (Transfer with checks and bills are not accepted.)
  • Customer is responsible for paying all possible charges,including sales tax, VAT and customs charges,etc.
  • If you need the detailed invoice or tax ID,please email us.
  • FedEx, DHL, and UPS can be selected.
  • You can select whether to charge shipping fee by your shipping account or to charge by our side.
  • Please confirm with the logistics company in advance if you are in a remote area. (It may cost extra fees (35-50 USD) for delivery at those areas.)
  • The shopping cart will automatically calculate the shipping cost.
  • Delivery time: At the same day (Order deadline is 2pm, HK Time).
  • Delivery date: usually 2 to 7 working days.
  • It is unable to appoint a date of delivery.
  • Tracking number will be sent once your order has been shipped. (It may take up to 24 hours before carriers display the info.)
In Stock: 101
Shipped from
HK warehouse
Expected Shipping Date
Nov 14 - Nov 18 2026
Pricing(USD)
Quantity Unit Price Ext. Price
1 $26.8100 $26.81
20 $25.4695 $509.39
40 $24.1290 $965.16
60 $22.7885 $1 367.31
100 $21.4480 $2 144.80
260 $20.1075 $5 227.95
500 $18.7670 $9 383.50

Current price of SP2-PL2-DC5V is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
