AZ943-1CH-12DE

Part No :: AZ943-1CH-12DE

Manufacturer: American Zettler

Description: 15A SUGAR CUBE RELAY

Catalog: Power Relays, Over 2 Amps

DataSheet: AZ943-1CH-12DE PDF

Availability: 347 pieces

Current price of AZ943-1CH-12DE is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

AZ943-1CH-12DE Specifications

Type	Description
Series:	-
Package:	Tray
Part Status:	Active
Mounting Type:	Through Hole
Coil Voltage:	12VDC
Contact Form:	SPDT (1 Form C)
Contact Rating (Current):	10 A
Switching Voltage:	277VAC, 30VDC - Max
Coil Current:	30 mA
Coil Type:	Non Latching
Features:	-
Termination Style:	PC Pin
Seal Rating:	Sealed - Fully
Coil Insulation:	Class B
Must Operate Voltage:	9 VDC
Must Release Voltage:	1.2 VDC
Operate Time:	10 ms
Release Time:	5 ms
Operating Temperature:	-40°C ~ 90°C
Contact Material:	Silver Tin Oxide (AgSnO)
Relay Type:	General Purpose
