JW1AHN-DC12V-F

Part No :: JW1AHN-DC12V-F

Manufacturer: Panasonic

Description: RELAY GEN PURPOSE SPST-NO 5A 12V

Catalog: Power Relays, Over 2 Amps

DataSheet: JW1AHN-DC12V-F PDF

Availability: 0 pieces

Current price of JW1AHN-DC12V-F is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

JW1AHN-DC12V-F Specifications

Type	Description
Series:	JW
Package:	Bulk
Part Status:	Active
Mounting Type:	Through Hole
Coil Voltage:	12VDC
Contact Form:	SPST-NO (1 Form A)
Contact Rating (Current):	5 A
Switching Voltage:	250VAC, 30VDC - Max
Coil Current:	44 mA
Coil Type:	Non Latching
Features:	-
Termination Style:	PC Pin
Seal Rating:	Sealed - Flux Protection
Coil Insulation:	Class E
Must Operate Voltage:	8.4 VDC
Must Release Voltage:	1.2 VDC
Operate Time:	15 ms
Release Time:	5 ms
Operating Temperature:	-40°C ~ 60°C
Contact Material:	Silver Tin Oxide (AgSnO)
Relay Type:	General Purpose
