JQ1A-B-24V-F

Part No :: JQ1A-B-24V-F

Manufacturer: Panasonic

Description: RELAY GEN PURPOSE SPST 5A 24V

Catalog: Power Relays, Over 2 Amps

DataSheet: JQ1A-B-24V-F PDF

Availability: 61 pieces

Current price of JQ1A-B-24V-F is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

JQ1A-B-24V-F Specifications

Type	Description
Series:	JQ
Package:	Bulk
Part Status:	Not For New Designs
Mounting Type:	Through Hole
Coil Voltage:	24VDC
Contact Form:	SPST-NO (1 Form A)
Contact Rating (Current):	5 A
Switching Voltage:	250VAC, 110VDC - Max
Coil Current:	8.3 mA
Coil Type:	Non Latching
Features:	-
Termination Style:	PC Pin
Seal Rating:	-
Coil Insulation:	Class B
Must Operate Voltage:	18 VDC
Must Release Voltage:	1.2 VDC
Operate Time:	20 ms
Release Time:	10 ms
Operating Temperature:	-40°C ~ 85°C
Contact Material:	Silver Tin Oxide (AgSnO)
Relay Type:	General Purpose
