JS1F-F-5V-F

Part No :: JS1F-F-5V-F

Manufacturer: Panasonic

Description: JS RELAY 1 FORM C 5V

Catalog: Power Relays, Over 2 Amps

DataSheet: JS1F-F-5V-F PDF

Availability: 0 pieces

Current price of JS1F-F-5V-F is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

JS1F-F-5V-F Specifications

Type	Description
Series:	JS
Package:	Box
Part Status:	Not For New Designs
Mounting Type:	Through Hole
Coil Voltage:	5VDC
Contact Form:	SPDT (1 Form C)
Contact Rating (Current):	10 A
Switching Voltage:	250VAC, 100VDC - Max
Coil Current:	72 mA
Coil Type:	Non Latching
Features:	-
Termination Style:	PC Pin
Seal Rating:	Sealed - Flux Protection
Coil Insulation:	Class F
Must Operate Voltage:	3.5 VDC
Must Release Voltage:	0.5 VDC
Operate Time:	10 ms
Release Time:	10 ms
Operating Temperature:	-40°C ~ 105°C
Contact Material:	Silver Tin Oxide (AgSnO)
Relay Type:	General Purpose
