3-1416100-8

Part No :: 3-1416100-8

Manufacturer: TE Connectivity Potter & Brumfield Relays

VIGOR # :: 4556565

Description: RELAY GEN PURPOSE SPDT 6A 115V

Catalog: Power Relays, Over 2 Amps

DataSheet: 3-1416100-8 PDF

Country of origin: -

Date code: -

3-1416100-8 Specifications

Type	Description
Series:	SNR, SCHRACK
Package:	Bulk
Part Status:	Obsolete
Mounting Type:	DIN Rail
Coil Voltage:	115VAC/DC
Contact Form:	SPDT (1 Form C)
Contact Rating (Current):	6 A
Switching Voltage:	400VAC - Max
Coil Current:	3.5 mA
Coil Type:	Non Latching
Features:	Socket Included
Termination Style:	Spring Terminal
Seal Rating:	Sealed - Fully
Coil Insulation:	-
Must Operate Voltage:	82 VAC/DC
Must Release Voltage:	9 VAC/DC
Operate Time:	12 ms
Release Time:	5 ms
Operating Temperature:	-40°C ~ 55°C
Contact Material:	Silver Tin Oxide (AgSnO)
Relay Type:	General Purpose
