HE05-1A83-02

Part No :: HE05-1A83-02

Manufacturer: Standex Electronics

Description: RELAY REED SPST 3A 5V

Catalog: Reed Relays

DataSheet: HE05-1A83-02 PDF

Availability: 0 pieces

Current price of HE05-1A83-02 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

HE05-1A83-02 Specifications

Type	Description
Series:	HE
Package:	Bulk
Part Status:	Active
Mounting Type:	Through Hole
Coil Voltage:	5VDC
Contact Form:	SPST-NO (1 Form A)
Contact Rating (Current):	3 A
Switching Voltage:	7500VAC, 7500VDC - Max
Coil Current:	100 mA
Coil Type:	Non Latching
Features:	-
Termination Style:	PC Pin
Seal Rating:	-
Must Operate Voltage:	4 VDC
Must Release Voltage:	0.75 VDC
Operate Time:	3 ms
Release Time:	1.5 ms
Operating Temperature:	-20°C ~ 70°C
Contact Material:	-
