| Type | Description |
|---|---|
| Series: | TX-TH |
| Package: | Tube |
| Part Status: | Active |
| Mounting Type: | Through Hole |
| Coil Voltage: | 9VDC |
| Contact Form: | DPDT (2 Form C) |
| Contact Rating (Current): | 2 A |
| Switching Voltage: | 250VAC, 220VDC - Max |
| Coil Current: | 15.5 mA |
| Coil Type: | Non Latching |
| Features: | - |
| Termination Style: | PC Pin |
| Seal Rating: | Sealed - Fully |
| Coil Insulation: | - |
| Must Operate Voltage: | 6.75 VDC |
| Must Release Voltage: | 0.9 VDC |
| Operate Time: | 4 ms |
| Release Time: | 4 ms |
| Operating Temperature: | -40°C ~ 85°C |
| Contact Material: | Silver (Ag), Gold (Au) |
| Relay Type: | General Purpose |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 10 | ||
| 40 | ||
| 80 | ||
| 120 | ||
| 280 | ||
| 520 | ||
| 1000 |
Current price of TX2-9V-TH is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
