Y1685V0005BA9W

Part No :: Y1685V0005BA9W

Manufacturer: VPG Foil

Description: RES NETWORK 2 RES MULT OHM 1505

Catalog: Arrays/Networks Resistors

DataSheet: Y1685V0005BA9W PDF

Availability: 0 pieces

Unit Price: ~~$8.55190~~

Current price of Y1685V0005BA9W is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

Y1685V0005BA9W Specifications

Type	Description
Series:	VFCD1505
Package:	Tray
Part Status:	Active
Circuit Type:	Voltage Divider
Resistance (Ohms):	5k, 10k
Tolerance:	±0.1%
Number of Resistors:	2
Resistor Matching Ratio:	±0.05%
Resistor-Ratio-Drift:	±0.4ppm/°C
Number of Pins:	3
Power Per Element:	50mW
Temperature Coefficient:	±0.2ppm/°C
Operating Temperature:	-55°C ~ 125°C
Applications:	Voltage Divider (TCR Matched)
Mounting Type:	Surface Mount
Package / Case:	1505 (3812 Metric)
Supplier Device Package:	-
Size / Dimension:	0.150" L x 0.050" W (3.81mm x 1.27mm)
Height - Seated (Max):	0.025" (0.64mm)

Please confirm the specifications of the products when ordering.
