TDS08SGNNTR04

Part No :: TDS08SGNNTR04

Manufacturer: TE Connectivity ALCOSWITCH Switches

Description: TRI-STATE DIP 8P G RAISED T&R

Catalog: DIP Switches

DataSheet: TDS08SGNNTR04 PDF

Availability: 0 pieces

Current price of TDS08SGNNTR04 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

TDS08SGNNTR04 Specifications

Type	Description
Series:	TDS
Package:	Tape & Reel (TR)
Part Status:	Active
Circuit:	SPST
Number of Positions:	8
Current Rating (Amps):	25mA
Voltage Rating:	24VDC
Actuator Type:	Slide (Standard)
Actuator Level:	Raised
Contact Material:	Copper Alloy
Contact Finish:	Gold
Height Above Board:	0.161" (4.10mm)
Mounting Type:	Surface Mount
Termination Style:	Gull Wing
Pitch:	0.100" (2.54mm), Full
Washable:	No
Features:	-
Operating Temperature:	-20°C ~ 85°C

Please confirm the specifications of the products when ordering.
