59166-1-U-00-A

Part No :: 59166-1-U-00-A

Manufacturer: Wickmann / Littelfuse

VIGOR # :: 4559700

Description: SWITCH REED SPST-NO 350MA 140V

Catalog: Magnetic, Reed Switches

DataSheet: 59166-1-U-00-A PDF

Current price of 59166-1-U-00-A is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

59166-1-U-00-A Specifications

Type	Description
Series:	59166
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Obsolete
Type:	Molded Body
Circuit:	SPST-NO
Operate Range:	20 ~ 25AT
Release Range:	-
Current - Switching:	350mA (AC), 500mA (DC)
Voltage - Switching AC:	140 V
Voltage - Switching DC:	200 V
Power - Rated:	10W
Operate Time:	0.6 ms
Release Time:	0.2 ms
Mounting Type:	Through Hole
Termination Style:	Axial
Length - Overall:	1.590" (40.39mm)
Size - Body:	0.630" L x 0.095" W x 0.095" H (16.00mm x 2.40mm x 2.40mm)
Height Above Board:	-
Operating Temperature:	-40°C ~ 125°C
Capacitance:	0.3 pF
Current - Carry:	800mA (DC)

Please confirm the specifications of the products when ordering.
