PA1005.070QNL

Part No :: PA1005.070QNL

Manufacturer: PulseLarsen Antenna

Description: CURR SENSE XFMR 1:70 20A SMD

Catalog: Current Sense Transformers

DataSheet: PA1005.070QNL PDF

Availability: 0 pieces

Unit Price: ~~$1.80000~~

Current price of PA1005.070QNL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

PA1005.070QNL Specifications

Type	Description
Series:	-
Package:	Tray
Part Status:	Active
Frequency Range:	50kHz ~ 1MHz
Type:	Invasive
Current Rating (Amps):	-
Inductance:	0.75mOhm Primary, 4.75Ohm Secondary
ET (Volt-Time):	AEC-Q200
Turns Ratio - Primary:Secondary:	Surface Mount
Current Ratio:	0.284" L x 0.330" W (7.21mm x 8.38mm)
DC Resistance (DCR):	0.217" (5.50mm)
Ratings:	Gull Wing

Please confirm the specifications of the products when ordering.
