R8315NL

Part No :: R8315NL

Manufacturer: PulseR (iNRCORE

Description: TRANSFORMER PLANAR 345UH

Catalog: Power Transformers

DataSheet: R8315NL PDF

Availability: 0 pieces

Unit Price: ~~$4.52880~~

Current price of R8315NL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

R8315NL Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Type:	Planar
Voltage - Primary:	-
Voltage - Secondary (Full Load):	-
Current - Output (Max):	-
Primary Winding(s):	Dual
Secondary Winding(s):	Dual, Multiple Taps
Center Tap:	Yes
Power - Max:	140W
Mounting Type:	Surface Mount
Termination Style:	Solder, Quick Connect
Size / Dimension:	23.37mm L x 21.59mm W
Height - Seated (Max):	9.70mm
Voltage - Isolation:	1750VDC
Weight:	-
