78601/2MC-R

Image is for reference,
please contact us to get the real picture

Part No :: 78601/2MC-R

Manufacturer: Murata Power Solutions

Description: PULSE XFMR 1:1 500UH

Catalog: Pulse Transformers

DataSheet: 78601/2MC-R PDF

Availability: 116 pieces

Unit Price: ~~$2.76000~~

Current price of 78601/2MC-R is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

78601/2MC-R Specifications

Type	Description
Series:	786
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Not For New Designs
Transformer Type:	General Purpose
Inductance:	500µH
ET (Volt-Time):	10VµS
Turns Ratio - Primary:Secondary:	1:1
Mounting Type:	Surface Mount
Size / Dimension:	0.375" L x 0.354" W (9.52mm x 9.00mm)
Height - Seated (Max):	0.250" (6.35mm)
Operating Temperature:	0°C ~ 70°C
