EPC3630G-LF

Image is for reference,
please contact us to get the real picture

Part No :: EPC3630G-LF

Manufacturer: PCA Electronics, Inc.

Description: POE FLYBACK XFM 24V, 84W

Catalog: Switching Converter, SMPS Transformers

DataSheet: EPC3630G-LF PDF

Availability: 248 pieces

Unit Price: ~~$12.67000~~

Current price of EPC3630G-LF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

EPC3630G-LF Specifications

Type	Description
Series:	EPC-EFD25
Package:	Tray
Part Status:	Active
Type:	For DC/DC Converters
Applications:	Flyback Converters
Intended Chipset:	LT4295
Chipset Manufacturer:	Analog Devices
Voltage - Primary:	40 ~ 57V
Voltage - Auxiliary:	24V
Voltage - Isolation:	1500Vrms
Inductance @ Frequency:	15µH @ 100KHz
Frequency:	250kHz
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Size / Dimension:	-
Height - Seated (Max):	0.540" (13.72mm)
Footprint:	1.036" L x 1.250" W (26.31mm x 31.75mm)
Style:	-
