K7812-3AR3 vs PT6304R

This detailed comparison of K7812-3AR3 and PT6304R in the DC DC Converters provides valuable insights into their specifications and features. Key aspects such as Manufacturer, Package, Mounting Type, and core parameters are thoroughly analyzed. This side-by-side comparison simplifies component selection. To learn more, explore their datasheets or request a quote directly.

K7812-3AR3

Mornsun

Request For Quote

PT6304R

Texas Instruments

Request For Quote

Specifications Hide identical items

Manufacturer	Mornsun	Texas Instruments
Package / Case	12-SIP Module	12-SIP Module
Description	DC DC CONVERTER 12V 36W	DC DC CONVERTER 12V
In Stock	1 201	842
Mounting Type	Through Hole	Through Hole
Part Status	Active	Obsolete
Series	K7812-3AR3	PT6300
Package	Tube	Tray
Type	Non-Isolated PoL Module	Non-Isolated PoL Module
Number of Outputs	1	1
Voltage - Input (Min)	16V	16V
Voltage - Input (Max)	36V	38V
Voltage - Output 1	12V	12V
Voltage - Output 2	-	-
Voltage - Output 3	-	-
Voltage - Output 4	-	-
Current - Output (Max)	3A	3A
Power (Watts)	36 W	-
Voltage - Isolation	-	-
Applications	ITE (Commercial)	ITE (Commercial)
Features	-	-
Operating Temperature	-40°C ~ 85°C	-40°C ~ 85°C
Efficiency	97%	91%
Size / Dimension	1.27" L x 0.36" W x 0.58" H (32.2mm x 9.1mm x 14.9mm)	-
Supplier Device Package	-	-
Control Features	-	-
Approval Agency	CE	-
Standard Number	-	-
