| Type | Description |
|---|---|
| Series: | SFV-R |
| Package: | Tape & Reel (TR)Cut Tape (CT) |
| Part Status: | Active |
| Flat Flex Type: | FFC, FPC |
| Mounting Type: | Surface Mount, Right Angle |
| Connector/Contact Type: | Contacts, Bottom |
| Number of Positions: | 5 |
| Pitch: | 0.020" (0.50mm) |
| Termination: | Solder |
| FFC, FCB Thickness: | 0.30mm |
| Height Above Board: | 0.071" (1.80mm) |
| Locking Feature: | Slide Lock |
| Cable End Type: | Tapered |
| Contact Material: | Phosphor Bronze |
| Contact Finish: | Tin |
| Housing Material: | Polyamide (PA), Nylon, Glass Filled, Halogen Free |
| Actuator Material: | Polyphenylene Sulfide (PPS), Glass Filled, Halogen Free |
| Features: | Zero Insertion Force (ZIF) |
| Voltage Rating: | 50V |
| Operating Temperature: | -55°C ~ 105°C |
| Material Flammability Rating: | UL94 V-0 |
| Quantity | Unit Price | Ext. Price |
|---|---|---|
| 1 | ||
| 3000 | ||
| 6000 | ||
| 9000 | ||
| 15000 | ||
| 30000 |
Current price of SFV5R-1STE1HLF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@Vigorcomp.com
