IRF5805TRPBF

Part No :: IRF5805TRPBF

Manufacturer: VIGOR

Description: IRF5805 - TRANSISTOR

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IRF5805TRPBF PDF

Availability: 0 pieces

Current price of IRF5805TRPBF is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IRF5805TRPBF Specifications

Type	Description
Series:	HEXFET®
Package:	Bulk
Part Status:	Active
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	30 V
Current - Continuous Drain (Id) @ 25°C:	3.8A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	98mOhm @ 3.8A, 10V
Vgs(th) (Max) @ Id:	2.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	17 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	511 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	2W (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	Micro6™(TSOP-6)
Package / Case:	SOT-23-6 Thin, TSOT-23-6
