NDF11N50ZG

Part No :: NDF11N50ZG

Manufacturer: VIGOR

Description: MOSFET N-CH 500V 12A TO220FP

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: NDF11N50ZG PDF

Availability: 3778 pieces

Current price of NDF11N50ZG is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

NDF11N50ZG Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	500 V
Current - Continuous Drain (Id) @ 25°C:	12A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	520mOhm @ 4.5A, 10V
Vgs(th) (Max) @ Id:	4.5V @ 100µA
Gate Charge (Qg) (Max) @ Vgs:	69 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	1.645 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	39W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220FP
Package / Case:	TO-220-3 Full Pack
