NTMFS5C628NLT1G

Image is for reference,
please contact us to get the real picture

Part No :: NTMFS5C628NLT1G

Manufacturer: Sanyo Semiconductor/ON Semiconductor

Description: MOSFET N-CH 60V 5DFN

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: NTMFS5C628NLT1G PDF

Availability: 0 pieces

Unit Price: ~~$1.31000~~

Current price of NTMFS5C628NLT1G is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

NTMFS5C628NLT1G Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	15A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	2.4mOhm @ 50A, 10V
Vgs(th) (Max) @ Id:	2V @ 135µA
Gate Charge (Qg) (Max) @ Vgs:	52 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	3600 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	3.7W (Ta), 110W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	5-DFN (5x6) (8-SOFL)
Package / Case:	8-PowerTDFN

Please confirm the specifications of the products when ordering.
