PMZB600UNELYL

Part No :: PMZB600UNELYL

Manufacturer: Nexperia

Description: MOSFET N-CH 20V 600MA DFN1006B-3

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: PMZB600UNELYL PDF

Availability: 10 pieces

Current price of PMZB600UNELYL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

PMZB600UNELYL Specifications

Type	Description
Series:	TrenchMOS™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	20 V
Current - Continuous Drain (Id) @ 25°C:	600mA (Ta)
Drive Voltage (Max Rds On, Min Rds On):	1.2V, 4.5V
Rds On (Max) @ Id, Vgs:	620mOhm @ 600mA, 4.5V
Vgs(th) (Max) @ Id:	950mV @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	0.7 nC @ 4.5 V
Vgs (Max):	±8V
Input Capacitance (Ciss) (Max) @ Vds:	21.3 pF @ 10 V
FET Feature:	-
Power Dissipation (Max):	360mW (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	DFN1006B-3
Package / Case:	3-XFDFN

Please confirm the specifications of the products when ordering.
