BSC118N10NSGATMA1

Part No :: BSC118N10NSGATMA1

Manufacturer: IR (Infineon Technologies)

Description: MOSFET N-CH 100V 11A/71A TDSON

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: BSC118N10NSGATMA1 PDF

Availability: 10642 pieces

Current price of BSC118N10NSGATMA1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

BSC118N10NSGATMA1 Specifications

Type	Description
Series:	OptiMOS™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	100 V
Current - Continuous Drain (Id) @ 25°C:	11A (Ta), 71A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	11.8mOhm @ 50A, 10V
Vgs(th) (Max) @ Id:	4V @ 70µA
Gate Charge (Qg) (Max) @ Vgs:	56 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	3700 pF @ 50 V
FET Feature:	-
Power Dissipation (Max):	114W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PG-TDSON-8-1
Package / Case:	8-PowerTDFN
