IPW60R045P7XKSA1

Image is for reference,
please contact us to get the real picture

Part No :: IPW60R045P7XKSA1

Manufacturer: IR (Infineon Technologies)

Description: MOSFET N-CH 650V 61A TO247-3-41

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IPW60R045P7XKSA1 PDF

Availability: 0 pieces

Unit Price: ~~$7.84000~~

Current price of IPW60R045P7XKSA1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IPW60R045P7XKSA1 Specifications

Type	Description
Series:	CoolMOS™ P7
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	650 V
Current - Continuous Drain (Id) @ 25°C:	61A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	45mOhm @ 22.5A, 10V
Vgs(th) (Max) @ Id:	4V @ 1.08mA
Gate Charge (Qg) (Max) @ Vgs:	90 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	3891 pF @ 400 V
FET Feature:	-
Power Dissipation (Max):	201W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	PG-TO247-3-41
Package / Case:	TO-247-3
