STP4NK80ZFP

Part No :: STP4NK80ZFP

Manufacturer: STMicroelectronics

Description: MOSFET N-CH 800V 3A TO220FP

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: STP4NK80ZFP PDF

Availability: 1000 pieces

Unit Price: ~~$2.01000~~

Current price of STP4NK80ZFP is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

STP4NK80ZFP Specifications

Type	Description
Series:	SuperMESH™
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	800 V
Current - Continuous Drain (Id) @ 25°C:	3A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	3.5Ohm @ 1.5A, 10V
Vgs(th) (Max) @ Id:	4.5V @ 50µA
Gate Charge (Qg) (Max) @ Vgs:	22.5 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	575 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	25W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220FP
Package / Case:	TO-220-3 Full Pack

Please confirm the specifications of the products when ordering.
