PSMN3R3-60PLQ

Part No :: PSMN3R3-60PLQ

Manufacturer: Nexperia

Description: MOSFET N-CH 60V 130A TO220AB

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: PSMN3R3-60PLQ PDF

Availability: 2157 pieces

Current price of PSMN3R3-60PLQ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

PSMN3R3-60PLQ Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	60 V
Current - Continuous Drain (Id) @ 25°C:	130A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	4.5V, 10V
Rds On (Max) @ Id, Vgs:	3.4mOhm @ 25A, 10V
Vgs(th) (Max) @ Id:	2.1V @ 1mA
Gate Charge (Qg) (Max) @ Vgs:	95 nC @ 5 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	10115 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	293W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220AB
Package / Case:	TO-220-3
