STW50N65DM2AG

Part No :: STW50N65DM2AG

Manufacturer: STMicroelectronics

Description: MOSFET N-CH 650V 28A TO247

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: STW50N65DM2AG PDF

Availability: 1188 pieces

Current price of STW50N65DM2AG is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

STW50N65DM2AG Specifications

Type	Description
Series:	Automotive, AEC-Q101, MDmesh™ DM2
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	650 V
Current - Continuous Drain (Id) @ 25°C:	28A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	87mOhm @ 19A, 10V
Vgs(th) (Max) @ Id:	5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	70 nC @ 10 V
Vgs (Max):	±25V
Input Capacitance (Ciss) (Max) @ Vds:	3200 pF @ 100 V
FET Feature:	-
Power Dissipation (Max):	300W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-247
Package / Case:	TO-247-3

Please confirm the specifications of the products when ordering.
