IXFH20N80P

Part No :: IXFH20N80P

Manufacturer: Wickmann / Littelfuse

Description: MOSFET N-CH 800V 20A TO247AD

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: IXFH20N80P PDF

Availability: 4 pieces

Current price of IXFH20N80P is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

IXFH20N80P Specifications

Type	Description
Series:	HiPerFET™, PolarHT™
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	800 V
Current - Continuous Drain (Id) @ 25°C:	20A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	520mOhm @ 10A, 10V
Vgs(th) (Max) @ Id:	5V @ 4mA
Gate Charge (Qg) (Max) @ Vgs:	86 nC @ 10 V
Vgs (Max):	±30V
Input Capacitance (Ciss) (Max) @ Vds:	4685 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	500W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-247AD (IXFH)
Package / Case:	TO-247-3

Please confirm the specifications of the products when ordering.
