PSMN6R3-120PS

Part No :: PSMN6R3-120PS

Manufacturer: Nexperia

Description: MOSFET N-CH 120V 70A TO220AB

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: PSMN6R3-120PS PDF

Availability: 3423 pieces

Current price of PSMN6R3-120PS is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

PSMN6R3-120PS Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	120 V
Current - Continuous Drain (Id) @ 25°C:	70A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	10V
Rds On (Max) @ Id, Vgs:	6.7mOhm @ 25A, 10V
Vgs(th) (Max) @ Id:	4V @ 1mA
Gate Charge (Qg) (Max) @ Vgs:	207.1 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	11384 pF @ 60 V
FET Feature:	-
Power Dissipation (Max):	405W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Through Hole
Supplier Device Package:	TO-220AB
Package / Case:	TO-220-3
