HUFA75639S3ST-F085A

Part No :: HUFA75639S3ST-F085A

Manufacturer: VIGOR

Description: MOSFET N-CH 100V 56A D2PAK

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: HUFA75639S3ST-F085A PDF

Availability: 766 pieces

Current price of HUFA75639S3ST-F085A is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

HUFA75639S3ST-F085A Specifications

Type	Description
Series:	UltraFET™
Package:	Bulk
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	100 V
Current - Continuous Drain (Id) @ 25°C:	56A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	-
Rds On (Max) @ Id, Vgs:	25mOhm @ 56A, 10V
Vgs(th) (Max) @ Id:	4V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	130 nC @ 20 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	2000 pF @ 25 V
FET Feature:	-
Power Dissipation (Max):	200W (Tc)
Operating Temperature:	-55°C ~ 175°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	D2PAK (TO-263)
Package / Case:	TO-263-3, D²Pak (2 Leads + Tab), TO-263AB

Please confirm the specifications of the products when ordering.
