BSC190N15NS3GATMA1

Part No :: BSC190N15NS3GATMA1

Manufacturer: IR (Infineon Technologies)

Description: MOSFET N-CH 150V 50A TDSON-8-1

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: BSC190N15NS3GATMA1 PDF

Availability: 16950 pieces

Current price of BSC190N15NS3GATMA1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

BSC190N15NS3GATMA1 Specifications

Type	Description
Series:	OptiMOS™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	N-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	150 V
Current - Continuous Drain (Id) @ 25°C:	50A (Tc)
Drive Voltage (Max Rds On, Min Rds On):	8V, 10V
Rds On (Max) @ Id, Vgs:	19mOhm @ 50A, 10V
Vgs(th) (Max) @ Id:	4V @ 90µA
Gate Charge (Qg) (Max) @ Vgs:	31 nC @ 10 V
Vgs (Max):	±20V
Input Capacitance (Ciss) (Max) @ Vds:	2420 pF @ 75 V
FET Feature:	-
Power Dissipation (Max):	125W (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PG-TDSON-8-1
Package / Case:	8-PowerTDFN
