CSD22206WT

Part No :: CSD22206WT

Manufacturer: Texas Instruments

Description: MOSFET P-CH 8V 5A 9DSBGA

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: CSD22206WT PDF

Availability: 2263 pieces

Current price of CSD22206WT is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CSD22206WT Specifications

Type	Description
Series:	NexFET™
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	8 V
Current - Continuous Drain (Id) @ 25°C:	5A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	2.5V, 4.5V
Rds On (Max) @ Id, Vgs:	5.7mOhm @ 2A, 4.5V
Vgs(th) (Max) @ Id:	1.05V @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	14.6 nC @ 4.5 V
Vgs (Max):	-6V
Input Capacitance (Ciss) (Max) @ Vds:	2275 pF @ 4 V
FET Feature:	-
Power Dissipation (Max):	1.7W (Ta)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	9-DSBGA (1.5x1.5)
Package / Case:	9-UFBGA, DSBGA
