PMPB10UPX

Part No :: PMPB10UPX

Manufacturer: Nexperia

Description: MOSFET P-CH 12V 10A DFN2020MD-6

Catalog: Transistors - FETs, MOSFETs - Single

DataSheet: PMPB10UPX PDF

Availability: 2755 pieces

Current price of PMPB10UPX is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

PMPB10UPX Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Last Time Buy
FET Type:	P-Channel
Technology:	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss):	12 V
Current - Continuous Drain (Id) @ 25°C:	10A (Ta)
Drive Voltage (Max Rds On, Min Rds On):	1.8V, 4.5V
Rds On (Max) @ Id, Vgs:	11.5mOhm @ 10A, 4.5V
Vgs(th) (Max) @ Id:	900mV @ 250µA
Gate Charge (Qg) (Max) @ Vgs:	40 nC @ 4.5 V
Vgs (Max):	±8V
Input Capacitance (Ciss) (Max) @ Vds:	2.2 nF @ 6 V
FET Feature:	-
Power Dissipation (Max):	1.7W (Ta), 13mW (Tc)
Operating Temperature:	-55°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	DFN2020MD-6
Package / Case:	6-UDFN Exposed Pad
