NGTB20N120IHSWG

NGTB20N120IHSWG

Image is for reference,
please contact us to get the real picture

Part No :

NGTB20N120IHSWG

Manufacturer
Sanyo Semiconductor/ON Semiconductor
Description
IGBT 1200V 20A TO247
Catalog
Transistors - IGBTs - Single
Shipped from
HK warehouse
Expected Shipping Date
Oct 14 - Oct 18 2025
DataSheet
NGTB20N120IHSWG PDF
Availability
0 pieces
Unit Price
$0.00000

Current price of NGTB20N120IHSWG is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team [email protected]

NGTB20N120IHSWG Specifications
Type Description
Series:-
Package:Tube
Part Status:Obsolete
IGBT Type:Trench Field Stop
Voltage - Collector Emitter Breakdown (Max):1200 V
Current - Collector (Ic) (Max):40 A
Current - Collector Pulsed (Icm):120 A
Vce(on) (Max) @ Vge, Ic:2.4V @ 15V, 20A
Power - Max:156 W
Switching Energy:650µJ (off)
Input Type:Standard
Gate Charge:155 nC
Td (on/off) @ 25°C:-/160ns
Test Condition:600V, 20A, 10Ohm, 15V
Reverse Recovery Time (trr):-
Operating Temperature:-55°C ~ 150°C (TJ)
Mounting Type:Through Hole
Package / Case:TO-247-3
Supplier Device Package:TO-247
