CM1485-02SE

Part No :: CM1485-02SE

Manufacturer: VIGOR

Description: DATA LINE FILTER

Catalog: EMI/RFI Filters (LC, RC Networks)

DataSheet: CM1485-02SE PDF

Availability: 12850 pieces

Current price of CM1485-02SE is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

CM1485-02SE Specifications

Type	Description
Series:	-
Package:	Bulk
Part Status:	Obsolete
Type:	Low Pass
Filter Order:	2nd
Technology:	RC (Pi)
Number of Channels:	2
Center / Cutoff Frequency:	125MHz (Cutoff)
Attenuation Value:	30dB @ 800MHz ~ 1GHz
Resistance - Channel (Ohms):	100
Current:	-
Values:	R = 100Ohms, C = 12pF
ESD Protection:	Yes
Operating Temperature:	-40°C ~ 85°C
Applications:	Data Lines for Mobile Devices
Voltage - Rated:	-
Mounting Type:	Surface Mount
Package / Case:	SOT-563, SOT-666
Size / Dimension:	0.063" L x 0.047" W (1.60mm x 1.20mm)
Height:	0.024" (0.60mm)

Please confirm the specifications of the products when ordering.
