PF0553.103NL

Image is for reference,
please contact us to get the real picture

Part No :: PF0553.103NL

Manufacturer: PulseLarsen Antenna

Description: INDUCT ARRAY 2 COIL 10.5UH SMD

Catalog: Arrays, Signal Transformers

DataSheet: PF0553.103NL PDF

Availability: 0 pieces

Unit Price: ~~$0.96100~~

Current price of PF0553.103NL is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

PF0553.103NL Specifications

Type	Description
Series:	PF0553NL
Package:	Tray
Part Status:	Active
Number of Coils:	2
Inductance - Connected In Parallel:	10.5 µH
Inductance - Connected In Series:	42 µH
Tolerance:	±20%
Current Rating - Parallel:	6 A
Current Rating - Series:	3 A
Current Saturation - Parallel:	11 A
Current Saturation - Series:	5.6 A
DC Resistance (DCR) - Parallel:	17mOhm Max
DC Resistance (DCR) - Series:	67mOhm Max
Shielding:	Shielded
Ratings:	-
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	Nonstandard
Size / Dimension:	0.492" L x 0.492" W (12.50mm x 12.50mm)
Height:	0.343" (8.71mm)
