MAX4547ESE+T

Part No :: MAX4547ESE+T

Manufacturer: Maxim Integrated

VIGOR # :: 4956428

Description: IC VIDEO SWITCH DUAL SPDT 16SOIC

Catalog: Interface - Analog Switches - Special Purpose

DataSheet: MAX4547ESE+T PDF

Country of origin: -

Date code: -

MAX4547ESE+T Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
Applications:	Video
Multiplexer/Demultiplexer Circuit:	2:1
Switch Circuit:	SPDT
Number of Channels:	2
On-State Resistance (Max):	20Ohm
Voltage - Supply, Single (V+):	2.7V ~ 12V
Voltage - Supply, Dual (V±):	±2.7V ~ 6V
-3db Bandwidth:	300MHz
Features:	Bi-Directional, Break-Before-Make, T-Switch Configuration
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Package / Case:	16-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	16-SO

Alternative Products

Part Number	Manufacturer & Description	Compare
MAX4546ESE+ Match 100%	Maxim Integrated IC VIDEO SWITCH DUAL SPST 16SOIC	MAX4547ESE+T vs MAX4546ESE+
MAX4567ESE+ Match 88%	Maxim Integrated IC SW DUAL VIDEO BIDIRECT 16SOIC	MAX4547ESE+T vs MAX4567ESE+
MAX4546ESE+T Match 100%	Maxim Integrated IC VIDEO SWITCH DUAL SPST 16SOIC	MAX4547ESE+T vs MAX4546ESE+T
MAX4547ESE+ Match 100%	Maxim Integrated IC VIDEO SWITCH DUAL SPDT 16SOIC	MAX4547ESE+T vs MAX4547ESE+
