PCA9536DR

Part No :: PCA9536DR

Manufacturer: Texas Instruments

VIGOR # :: 3933761

Description: IC I/O EXPANDER I2C 4B 8SOIC

Catalog: Interface - I/O Expanders

DataSheet: PCA9536DR PDF

Country of origin: -

Date code: -

PCA9536DR Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Number of I/O:	4
Interface:	I²C, SMBus
Interrupt Output:	No
Features:	POR
Output Type:	Push-Pull
Current - Output Source/Sink:	10mA, 25mA
Clock Frequency:	400 kHz
Voltage - Supply:	2.3V ~ 5.5V
Operating Temperature:	-40°C ~ 85°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
