SN74HC109NS

Part No :: SN74HC109NS

Manufacturer: VIGOR

VIGOR # :: 3826095

Description: IC JK TYPE POS TRG DUAL 16SO

Catalog: Logic - Flip Flops

DataSheet: SN74HC109NS PDF

Country of origin: -

Date code: -

SN74HC109NS Specifications

Type	Description
Series:	74HC
Package:	Bulk
Part Status:	Active
Function:	Set(Preset) and Reset
Type:	JK Type
Output Type:	Complimentary
Number of Elements:	2
Number of Bits per Element:	1
Clock Frequency:	60 MHz
Max Propagation Delay @ V, Max CL:	30ns @ 6V, 50pF
Trigger Type:	Positive Edge
Current - Output High, Low:	5.2mA, 5.2mA
Voltage - Supply:	2V ~ 6V
Current - Quiescent (Iq):	4 µA
Input Capacitance:	3 pF
Operating Temperature:	-40°C ~ 85°C (TA)
Mounting Type:	Surface Mount
Supplier Device Package:	16-SO
Package / Case:	16-SOIC (0.209", 5.30mm Width)

Alternative Products

Part Number	Manufacturer & Description	Compare
74HC109D,652 Match 82%	Nexperia IC FF JK TYPE DUAL 1BIT 16SO	SN74HC109NS vs 74HC109D,652
SN74HC109NSR Match 100%	VIGOR SN74HC109 DUAL J-K POSITIVE-EDGE	SN74HC109NS vs SN74HC109NSR
SN74HC109NSRE4 Match 100%	VIGOR SN74HC109 DUAL J-K POSITIVE-EDGE	SN74HC109NS vs SN74HC109NSRE4
74HC109D,653 Match 82%	Nexperia IC FF JK TYPE DUAL 1BIT 16SO	SN74HC109NS vs 74HC109D,653
74HC112D,653 Match 88%	Nexperia IC FF JK TYPE DUAL 1BIT 16SO	SN74HC109NS vs 74HC112D,653
74HC112D,652 Match 88%	Nexperia IC FF JK TYPE DUAL 1BIT 16SO	SN74HC109NS vs 74HC112D,652
