NCV5701ADR2G

Part No :: NCV5701ADR2G

Manufacturer: Sanyo Semiconductor/ON Semiconductor

VIGOR # :: 3881336

Description: IC GATE DRVR HI/LOW SIDE 8SOIC

Catalog: PMIC - Gate Drivers

DataSheet: NCV5701ADR2G PDF

Country of origin: -

Date code: -

NCV5701ADR2G Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)
Part Status:	Active
Driven Configuration:	High-Side or Low-Side
Channel Type:	Single
Number of Drivers:	1
Gate Type:	IGBT
Voltage - Supply:	20V
Logic Voltage - VIL, VIH:	0.75V, 4.3V
Current - Peak Output (Source, Sink):	20mA, 15mA
Input Type:	Inverting
High Side Voltage - Max (Bootstrap):	-
Rise / Fall Time (Typ):	9.2ns, 7.9ns
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC

Alternative Products

Part Number	Manufacturer & Description	Compare
NCV5701BDR2G Match 100%	VIGOR HIGH CURRENT IGBT GATE DR	NCV5701ADR2G vs NCV5701BDR2G
NCV5702DR2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE DRVR HALF-BRIDGE 16SOIC	NCV5701ADR2G vs NCV5702DR2G
NCV5703ADR2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE DRVR HALF-BRIDGE 8SOIC	NCV5701ADR2G vs NCV5703ADR2G
NCV5703CDR2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE DRVR HALF-BRIDGE 8SOIC	NCV5701ADR2G vs NCV5703CDR2G
NCD5701BDR2G Match 100%	Sanyo Semiconductor/ON Semiconductor IC GATE DRVR LOW-SIDE 8SOIC	NCV5701ADR2G vs NCD5701BDR2G
NCV57200DR2G Match 100%	Sanyo Semiconductor/ON Semiconductor ISOLATED COMPACT IGBT GATE DRIVE	NCV5701ADR2G vs NCV57200DR2G
