AL5802-7

Part No :: AL5802-7

Manufacturer: Zetex Semiconductors (Diodes Inc.)

VIGOR # :: 3923455

Description: IC LED DRVR LIN DIM 120MA SOT26

Catalog: PMIC - LED Drivers

DataSheet: AL5802-7 PDF

Country of origin: -

Date code: -

AL5802-7 Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Type:	Linear
Topology:	-
Internal Switch(s):	Yes
Number of Outputs:	1
Voltage - Supply (Min):	4.5V
Voltage - Supply (Max):	30V
Voltage - Output:	0.8V ~ 30V
Current - Output / Channel:	120mA
Frequency:	-
Dimming:	PWM
Applications:	Signage
Operating Temperature:	-40°C ~ 125°C (TA)
Mounting Type:	Surface Mount
Package / Case:	SOT-23-6
Supplier Device Package:	SOT-26

Alternative Products

Part Number	Manufacturer & Description	Compare
A6284KLPTR-T-1 Match 100%	Allegro MicroSystems IC LED DRVR LINEAR 120MA 20TSSOP	AL5802-7 vs A6284KLPTR-T-1
TLD2311ELXUMA1 Match 100%	IR (Infineon Technologies) IC LED DRIVER LINEAR 14SSOP	AL5802-7 vs TLD2311ELXUMA1
TLD2326ELXUMA1 Match 100%	VIGOR TLD2326 - 3 CHANNEL HIGH SIDE CU	AL5802-7 vs TLD2326ELXUMA1
TLD1314ELXUMA1 Match 100%	IR (Infineon Technologies) IC LED DRIVER LIN 120MA 14SSOP	AL5802-7 vs TLD1314ELXUMA1
TLD1326ELXUMA1 Match 100%	VIGOR TLD1326 - 3 CHANNEL HIGH SIDE CU	AL5802-7 vs TLD1326ELXUMA1
TLD22522EPXUMA1 Match 100%	IR (Infineon Technologies) IC GATE DRIVER HIS SIDE	AL5802-7 vs TLD22522EPXUMA1
