TB6561NG

Part No :: TB6561NG

Manufacturer: Toshiba Electronic Devices and Storage Corporation

VIGOR # :: 4919107

Description: IC MOTOR DRIVER 10V-36V 24SDIP

Catalog: PMIC - Motor Drivers, Controllers

DataSheet: TB6561NG PDF

Country of origin: -

Date code: -

TB6561NG Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Obsolete
Motor Type - Stepper:	-
Motor Type - AC, DC:	Brushed DC
Function:	Driver - Fully Integrated, Control and Power Stage
Output Configuration:	Half Bridge (4)
Interface:	PWM
Technology:	Bi-CMOS
Step Resolution:	-
Applications:	General Purpose
Current - Output:	1.5A
Voltage - Supply:	10V ~ 36V
Voltage - Load:	10V ~ 36V
Operating Temperature:	-20°C ~ 85°C (TA)
Mounting Type:	Through Hole
Package / Case:	24-SDIP (0.300", 7.62mm)
Supplier Device Package:	24-SDIP
