BTS54220LBBAUMA1

Image is for reference,
please contact us to get the real picture

Part No :: BTS54220LBBAUMA1

Manufacturer: VIGOR

Description: SPOC SPI POWER CONTROLLER

Catalog: PMIC - Power Distribution Switches, Load Drivers

DataSheet: BTS54220LBBAUMA1 PDF

Availability: 2500 pieces

Unit Price: ~~$3.37000~~

Current price of BTS54220LBBAUMA1 is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

BTS54220LBBAUMA1 Specifications

Type	Description
Series:	Automotive
Package:	Bulk
Part Status:	Active
Switch Type:	General Purpose
Number of Outputs:	4
Ratio - Input:Output:	1:1
Output Configuration:	High Side
Output Type:	N-Channel
Interface:	SPI
Voltage - Load:	5.5V ~ 28V
Voltage - Supply (Vcc/Vdd):	3.8V ~ 5.5V
Current - Output (Max):	5A
Rds On (Typ):	9mOhm
Input Type:	-
Features:	-
Fault Protection:	Current Limiting (Fixed), Over Temperature, Over Voltage
Operating Temperature:	-40°C ~ 150°C (TJ)
Mounting Type:	Surface Mount
Supplier Device Package:	PG-TSON-24-3
Package / Case:	24-PowerVDFN

Please confirm the specifications of the products when ordering.
