AS7809ATF-E1

Part No :: AS7809ATF-E1

Manufacturer: Zetex Semiconductors (Diodes Inc.)

VIGOR # :: 3765100

Description: IC REG LINEAR 9V 1A TO220-3

Catalog: PMIC - Voltage Regulators - Linear

DataSheet: AS7809ATF-E1 PDF

Country of origin: -

Date code: -

AS7809ATF-E1 Specifications

Type	Description
Series:	-
Package:	Tube
Part Status:	Active
Output Configuration:	Positive
Output Type:	Fixed
Number of Regulators:	1
Voltage - Input (Max):	29V
Voltage - Output (Min/Fixed):	9V
Voltage - Output (Max):	-
Voltage Dropout (Max):	2V @ 1A (Typ)
Current - Output:	1A
Current - Quiescent (Iq):	6 mA
Current - Supply (Max):	-
PSRR:	61dB (120Hz)
Control Features:	-
Protection Features:	Over Temperature, Short Circuit
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Through Hole
Package / Case:	TO-220-3
Supplier Device Package:	TO-220-3
