ACPL-P345-500E

Part No :: ACPL-P345-500E

Manufacturer: Broadcom

VIGOR # :: 4088867

Description: OPTOISO 3.75KV 1CH GATE DRVR 6SO

Catalog: Isolators - Gate Drivers

DataSheet: ACPL-P345-500E PDF

Country of origin: -

Date code: -

ACPL-P345-500E Specifications

Type	Description
Series:	-
Package:	Tape & Reel (TR)Cut Tape (CT)
Part Status:	Active
Technology:	Optical Coupling
Number of Channels:	1
Voltage - Isolation:	3750Vrms
Common Mode Transient Immunity (Min):	50kV/µs
Propagation Delay tpLH / tpHL (Max):	120ns, 120ns
Pulse Width Distortion (Max):	50ns
Rise / Fall Time (Typ):	8ns, 8ns
Current - Output High, Low:	800mA, 800mA
Current - Peak Output:	1A
Voltage - Forward (Vf) (Typ):	1.55V
Current - DC Forward (If) (Max):	25 mA
Voltage - Output Supply:	10V ~ 20V
Operating Temperature:	-40°C ~ 105°C
Mounting Type:	Surface Mount
Package / Case:	6-SOIC (0.268", 6.80mm Width)
Supplier Device Package:	6-SO Stretched
Approval Agency:	CSA, UR
