ADUM3220WARZ

Part No :: ADUM3220WARZ

Manufacturer: Linear Technology (Analog Devices, Inc.)

Description: DGTL ISO 2.5KV GATE DRIVER 8SOIC

Catalog: Isolators - Gate Drivers

DataSheet: ADUM3220WARZ PDF

Availability: 0 pieces

Current price of ADUM3220WARZ is for reference only, if you want to get best price, please submit a inquiry or direct email to our sales team sales@vigor.vom.SG

ADUM3220WARZ Specifications

Type	Description
Series:	Automotive
Package:	Tube
Part Status:	Active
Technology:	Magnetic Coupling
Number of Channels:	2
Voltage - Isolation:	2500Vrms
Common Mode Transient Immunity (Min):	25kV/µs
Propagation Delay tpLH / tpHL (Max):	60ns, 60ns
Pulse Width Distortion (Max):	-
Rise / Fall Time (Typ):	20ns, 20ns
Current - Output High, Low:	-
Current - Peak Output:	4A
Voltage - Forward (Vf) (Typ):	-
Current - DC Forward (If) (Max):	-
Voltage - Output Supply:	4.5V ~ 18V
Operating Temperature:	-40°C ~ 125°C
Mounting Type:	Surface Mount
Package / Case:	8-SOIC (0.154", 3.90mm Width)
Supplier Device Package:	8-SOIC
Approval Agency:	CSA, UR, VDE

Please confirm the specifications of the products when ordering.
